WF210000
AC Solid State Relay, Zero Switch, 24-280VAC, 2A, 4-30VDC
Manufacturer:
Celduc RelaisCategory:
Relays & Switches
Sub Category:
DIP / Slide / Rotary Switches
Datasheet
WF210000 Datasheet
Product Description
The Celduc Relais WF210000 is a high-performance AC Solid State Relay (SSR) available at Supreme Components International, an authorised distributor. This zero-switching SSR is designed for switching AC loads with enhanced reliability and longevity compared to electromechanical relays. It features an output voltage range of 24-280VAC and a current rating of 2A. The control voltage is 4-30VDC, providing compatibility with a wide range of control circuits. Zero-switching relays turn on when the AC sine wave crosses zero, minimizing inrush current and electrical noise. This SSR is suitable for applications such as lighting control, heating control, and motor control where silent, fast, and reliable switching is required. Benefit from Celduc's quality and Supreme Components International's reliable distribution.
Technical Specifications
| Attribute | Description |
|---|---|
| Approvals | UL, VDE, CE |
| Load Current | 2 Amperes |
| Load Voltage | 24 to 280 Volts AC |
| Input Current | 12 Milliamperes |
| Mounting Type | Panel Mount |
| Switching Mode | Zero Switch |
| Control Voltage | 4 to 30 Volts DC |
| Leakage Current | 1 Milliampere |
| Termination Style | Screw Terminal |
| Input Voltage Drop | 1.3 Volts DC |
| Peak Surge Current | 30 Amperes |
| Operating Temperature | -30 Degrees Celsius to +80 Degrees Celsius |
