Manufacturer Part Number (MPN) UESD55B
Manufacturer Union Semiconductor
Short Description ESD protection diode, low capacitance, SOD-523 package
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Union Semiconductor. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Capacitance
0.3 picoFarads
Package Type
SOD-523
Voltage Rating
5.5 Volts
Peak Pulse Current
5 Amperes
Typical Clamping Voltage
9 Volts
Minimum Breakdown Voltage
6 Volts

Ordering Information

Parameter
Value
Packaging Type
TAPE_AND_REEL

Full Description

The UESD55B is a high-performance ESD protection diode manufactured by Union Semiconductor. This device is specifically engineered to protect sensitive electronic circuits from damage caused by electrostatic discharge (ESD) events. Its low capacitance design ensures minimal signal distortion, making it suitable for high-speed data lines and other critical applications. The UESD55B comes in a small SOD-523 package, allowing for easy integration into space-constrained designs. As an authorised distributor of Union Semiconductor, Supreme Components International guarantees the authenticity and quality of this ESD protection diode. This diode is ideal for protecting I/O interfaces, data lines, and other vulnerable components in portable devices, communication equipment, and industrial electronics.
