SU842070
Solid State Relay, Zero Switch, 24-280VAC, 24VAC Control, 2A, PCB Mount
Brand
Product Category
Relays & Switches
Product Sub category
DIP / Slide / Rotary Switches
PRODUCT DETAILS
Product Description
Supreme Components International, an authorised distributor, presents the CELDUC RELAIS SU842070, a high-performance Solid State Relay (SSR) optimized for PCB mounting. This zero-switch relay ensures clean and efficient switching of AC loads, minimizing electromagnetic interference (EMI). The SU842070 is designed to switch 24-280VAC loads with a maximum current of 2A, controlled by a 24VAC input signal. Its zero-crossing detection feature ensures that switching occurs at the zero-voltage point of the AC waveform, reducing inrush current and extending the lifespan of connected loads. This SSR is ideal for various applications, including industrial automation, lighting control, and heating systems. Its compact size and PCB-mountable design simplify integration into existing electronic circuits.
Product Tags
Technical Specifications
| Approvals | UL, VDE, CE |
|---|---|
| I squared t | 18 Ampere Squared Seconds |
| Load current | 2 Amperes |
| Input current | 12 Milliamperes |
| Mounting type | PCB Mount |
| Switching mode | Zero Switch |
| Control voltage | 24 Volts AC |
| Leakage current | 1.5 Milliamperes |
| Load voltage range | 24 to 280 Volts AC |
| Dielectric strength | 4000 Volts RMS |
| Input voltage range | 18 to 36 Volts AC |
| Output voltage drop | 1.6 Volts |
| Operating temperature | -30 Degrees Celsius to +80 Degrees Celsius |
