SO763090
Solid State Relay, Zero Voltage, 30A, 24-280VAC Output, 4-15VDC Input, PCB Mount
Brand
Product Category
Relays & Switches
Product Sub category
DIP / Slide / Rotary Switches
PRODUCT DETAILS
Product Description
Supreme Components International, an authorised distributor, presents the CELDUC RELAIS SO763090, a high-performance solid state relay (SSR) designed for PCB mounting. This zero-voltage switching SSR offers a robust 30A current rating and an output voltage range of 24-280VAC, making it suitable for a wide array of applications. The SO763090 features a 4-15VDC input, providing convenient control from various logic circuits. Its compact PCB mount design simplifies installation and integration into existing systems. Benefit from the reliability and silent operation of solid-state technology with this CELDUC RELAIS SSR. Ideal for industrial automation, lighting control, and heating applications.
Product Tags
Technical Specifications
| Approvals | UL, VDE, CE |
|---|---|
| Input type | Direct Current |
| Output type | Alternating Current |
| Load current | 30 Amperes |
| Load voltage | 24 to 280 Volts Alternating Current |
| Input current | 12 Milliamperes |
| Mounting type | Printed Circuit Board Mount |
| Switching mode | Zero Voltage |
| Control voltage | 4 to 15 Volts Direct Current |
| Leakage current | 1.5 Milliamperes |
| Output voltage drop | 1.6 Volts |
| Operating temperature | -30 Degrees Celsius to +80 Degrees Celsius |
