Reference Only
SM4F24CA-MS-Q1-H
TVS Diode, 400 W, 24V, DO-214AA
Datasheet
SM4F24CA-MS-Q1-H Datasheet
Product Description
Supreme Components International, an authorised distributor, presents the SM4F24CA-MS-Q1-H, a high-performance TVS Diode manufactured by FORMOSA MICROSEMI. This diode is specifically engineered to safeguard electronic circuits from transient voltage events, offering a robust solution for overvoltage protection. With a power dissipation rating of 400W and a reverse standoff voltage of 24V, the SM4F24CA-MS-Q1-H effectively clamps voltage spikes, preventing damage to sensitive components. Its DO-214AA (SMB) package ensures ease of installation and reliable thermal performance. Ideal for automotive, industrial, and consumer electronics applications, this TVS diode provides essential protection against electrostatic discharge (ESD), electrical fast transients (EFT), and lightning surges. Choose the SM4F24CA-MS-Q1-H for superior circuit protection and enhanced system reliability.
Technical Specifications
| Attribute | Description |
|---|---|
| Polarity | Bidirectional |
| Package_Type | DO-214AA (SMB) |
| Voltage_Rating | 24 Volts |
| Clamping_Voltage | 39.4 Volts |
| Power_Dissipation | 400 Watts |
| Peak_Pulse_Current | 10.2 Amperes |
| Maximum_Breakdown_Voltage | 29.5 Volts |
| Minimum_Breakdown_Voltage | 26.7 Volts |
Ordering Information
| Attribute | Description |
|---|---|
| Packaging Type | Tape And Reel |
