SKLD31006
Solid State Relay, DIN Rail Mount, 6A, 24-280VAC Output, 4-32VDC Input
Brand
Product Category
Relays & Switches
Product Sub category
DIP / Slide / Rotary Switches
PRODUCT DETAILS
Product Description
The SKLD31006 is a robust and efficient Solid State Relay (SSR) manufactured by CELDUC RELAIS. Supreme Components International is an authorised distributor of CELDUC RELAIS products. This DIN Rail Mount SSR is designed for easy installation and reliable performance in industrial environments. It features a 24-280VAC output voltage range, allowing it to switch a wide range of AC loads. The 4-32VDC input voltage provides compatibility with various control systems. With a 6A current rating, the SKLD31006 is suitable for controlling motors, heaters, lighting, and other inductive or resistive loads. Its solid-state design ensures long life and silent operation compared to electromechanical relays. Ideal for automation, process control, and other applications requiring reliable switching.
Product Tags
Technical Specifications
| Approvals | UL, CSA, VDE, CE |
|---|---|
| Load current | 6 Amperes |
| Load voltage | 24 to 280 Volts AC |
| Input current | 12 Milliamperes |
| Mounting type | DIN Rail |
| Switching mode | Zero Voltage Switching |
| Control voltage | 4 to 32 Volts DC |
| Leakage current | 1.5 Milliamperes |
| Peak surge current | 80 Amperes |
| Dielectric strength | 4 Kilovolts AC |
| Input voltage range | 4 to 32 Volts DC |
| Output voltage range | 24 to 280 Volts AC |
| Operating temperature | -30 Degrees Celsius to +80 Degrees Celsius |
