SGM40560
Single-Cell Li-Ion/Li-Polymer Charger, 500mA, Thermal Protection
Brand
Product Category
Power Management
Product Sub category
Battery Management and Protection Ics
SKU
84f034bef469
Packaging Type
Tape And Reel
PRODUCT DETAILS
Product Description
The SGM40560, manufactured by SG MICRO, is a high-performance linear charger designed for single-cell Li-Ion and Li-Polymer batteries. Supreme Components International is an authorised distributor of SG MICRO components. This charger offers a constant current/constant voltage charging algorithm with thermal protection to prevent overheating during the charging process. The SGM40560 features a 500mA maximum charging current, making it suitable for a wide range of portable devices. Its simple design requires minimal external components, reducing the overall system cost and complexity. The integrated thermal protection enhances safety and reliability, ensuring optimal battery performance and longevity. This device is ideal for applications where space and cost are critical considerations.
Product Tags
Technical Specifications
| Package type | TDFN-2x2-8L |
|---|---|
| Input voltage range | 4.35 Volts to 6.5 Volts |
| Precharge current level | 10 percent of programmed charge current |
| Thermal regulation feature | Yes |
| Operating temperature range | -40 degrees Celsius to +85 degrees Celsius |
| Programmable charge current maximum | Up to 500 milliamperes |
Ordering Information
| Packaging Type | Tape And Reel |
|---|
