SGM3142
Single channel load switch with controlled turn on.
Datasheet
SGM3142 Datasheet
Product Description
The SGM3142, manufactured by SG Micro, is a high-performance, single-channel load switch designed for power management applications. Featuring a low Ron, this switch minimizes power loss and maximizes efficiency. The controlled turn-on characteristic prevents inrush current, protecting sensitive components and ensuring system stability. This device is ideal for a wide range of applications, including portable devices, power distribution systems, and battery-powered equipment. Supreme Components International is an authorized distributor of SG Micro electronic components, ensuring you receive genuine and reliable parts. Benefit from controlled power delivery and enhanced system reliability with the SGM3142. Choose Supreme Components International for your electronic component needs.
Technical Specifications
| Attribute | Description |
|---|---|
| Package Type | STDFN-1.2x1.6-6L |
| On Resistance | 75 milliohms (Input Voltage = 5 Volts) |
| Current Rating | 2 Amperes |
| Voltage Rating | 1.5 Volts to 5.5 Volts |
| Shutdown Current | 0.1 microamperes (Typical) |
| Quiescent Current | 0.6 microamperes (Typical) |
