RDS6-8S-1065-D
8 Position, Through Hole, 2.54 mm Pitch, Flush Cross Actuator, DIP Switch
Product Category
Switches
Product Sub category
Dip/rotary switch
PRODUCT DETAILS
Product Description
8 Position, Through Hole, 2.54 mm Pitch, Flush Cross Actuator, DIP Switch
Product Tags
Technical Specifications
| Actuator level | Flush |
|---|---|
| Actuator style | Cross |
| Actuator type | Rotary |
| Cap | No |
| Dimensions lxwxh (in) | 0.393 x 0.393 x 0.256 |
| Dimensions lxwxh (mm) | 10 x 10 x 6.5 |
| Height (mm) | 0.256 |
| Length (mm) | 0.393 |
| Mounting style | Through Hole |
| Non-switching current rating (ma) | 200 |
| Non-switching voltage rating (vdc) | 42 |
| Number of positions | 8 |
| Operating temp max (°c) | 85 |
| Operating temp min (°c) | *-40 |
| Orientation | Horizontal |
| Pitch (mm) | 2.54 |
| Series | RDS6-1065-D |
| Switch type | DIP |
| Switching current rating (ma) | 150 |
| Switching voltage rating (vdc) | 42 |
| Termination | PC Pin |
| Washable | No |
| Width (mm) | 0.393 |
