| Manufacturer Part Number (MPN) | RDS3-8S-1012-2-RA-508-D |
| Manufacturer | Same Sky (formerly CUI Devices) |
| Short Description | 8 Position, Through Hole, 5.08 mm Pitch, Right Angle, Flush Cross Actuator w/ Cap, DIP Switch |
Request for Quotation
Supreme Components is an authorized distributor of Same Sky (formerly CUI Devices). We do not carry stock of this item but can quote upon request. Submit your request using the form.
Product Attributes
TYPE
DESCRIPTION
Category
Actuator Level
Flush
Actuator Style
Cross
Actuator Type
Rotary
Cap
Yes
Dimensions Lxwxh (in)
0.393 x 0.374 x 0.393
Dimensions Lxwxh (mm)
10 x 9.5 x 10
Height (mm)
10
Length (mm)
10
Mounting Style
Through Hole
Non-switching Current Rating (ma)
200
Non-switching Voltage Rating (vdc)
42
Number Of Positions
8
Operating Temp Max (°c)
85
Operating Temp Min (°c)
*-40
Orientation
Horizontal
Pitch (mm)
5.08
Series
RDS3-1012-RA
Switch Type
DIP
Switching Current Rating (ma)
150
Switching Voltage Rating (vdc)
42
Termination
PC Pin
Washable
No
Width (mm)
9.5
Full Description
8 Position, Through Hole, 5.08 mm Pitch, Right Angle, Flush Cross Actuator w/ Cap, DIP Switch
