RDS-10S-7229-R-JSMT
10 Position, Surface Mount, 5.08 mm Pitch, IP67, Flat Arrow Rotary Actuator, DIP Switch
Product Category
Switches
Product Sub category
Dip/rotary switch
PRODUCT DETAILS
Product Description
10 Position, Surface Mount, 5.08 mm Pitch, IP67, Flat Arrow Rotary Actuator, DIP Switch
Product Tags
Technical Specifications
| Actuator level | Raised |
|---|---|
| Actuator style | Arrow |
| Actuator type | Rotary |
| Cap | No |
| Dimensions lxwxh (in) | 0.28 x 0.28 x 0.11 |
| Dimensions lxwxh (mm) | 7.2 x 7.2 x 2.9 |
| Height (mm) | 2.9 |
| Ip rating | IP67 |
| Length (mm) | 7.2 |
| Mounting style | SMT |
| Non-switching current rating (ma) | 100 |
| Non-switching voltage rating (vdc) | 50 |
| Number of positions | 10 |
| Operating temp max (°c) | 85 |
| Operating temp min (°c) | -40 |
| Orientation | Horizontal |
| Pitch (mm) | 5.08 |
| Series | RDS-7229-JSMT |
| Switch type | DIP |
| Switching current rating (ma) | 100 |
| Switching voltage rating (vdc) | 50 |
| Termination | J-Hook Gull Wing |
| Washable | No |
| Width (mm) | 7.2 |
