Reference Only
PD410PI2E00F
Description: PHOTODIODES OPTO PIN, Photodiode 1000nm 200ns 90° Radial, Side View; Features: PIN type; Package(Meterial): Visible light cut-off epoxy resin with condenser(lens); Active area(mm²): 3.31; Topr(°C): -25 to +85; ISC MIN(µA): 2.5; tr, tf(µs)TYP.: 0.2; tr, tf(μs)VR(V): 10; tr, tf(μs)RL(kΩ): 1; λp TYP(nm): 1000; Standard package: 2000; Packaging: 2 vinyl bag; ROHS: Y
Manufacturer:
Socle (Sharp)Category:
Integrated Circuits (ics), Optoelectronics
Sub Category:
Other
Product Description
Description: PHOTODIODES OPTO PIN, Photodiode 1000nm 200ns 90° Radial, Side View; Features: PIN type; Package(Meterial): Visible light cut-off epoxy resin with condenser(lens); Active area(mm²): 3.31; Topr(°C): -25 to +85; ISC MIN(µA): 2.5; tr, tf(µs)TYP.: 0.2; tr, tf(μs)VR(V): 10; tr, tf(μs)RL(kΩ): 1; λp TYP(nm): 1000; Standard package: 2000; Packaging: 2 vinyl bag; ROHS: Y
