PC20G
Thermoelectric Cooler, 40 x 40 x 3.3mm, 20W
Manufacturer:
LAIRD Connectivity (now Ezurio)Sub Category:
RF & Wireless Components
Datasheet
PC20G Datasheet
Product Description
Supreme Components International, an authorised distributor, presents the PC20G thermoelectric cooler (TEC) manufactured by LAIRD CONNECTIVITY (EZURIO). This TEC is designed for efficient and reliable temperature control in various applications. With dimensions of 40 x 40 x 3.3mm and a 20W cooling capacity, the PC20G offers a compact and powerful solution for thermal management. Thermoelectric coolers utilize the Peltier effect to create a heat flux between two different materials. This TEC is suitable for applications such as laser diode cooling, portable refrigerators, and temperature stabilization. Choose Supreme Components International for genuine LAIRD CONNECTIVITY (EZURIO) components and expert support.
Technical Specifications
| Attribute | Description |
|---|---|
| Dimensions | 40 x 40 x 3.3 millimeters |
| Maximum_Current | 4.2 Amperes |
| Maximum_Voltage | 4.2 Volts |
| Hot_Side_Temperature | 25 Degrees Celsius |
| Electrical_Resistance | 0.85 Ohms |
| Maximum_Cooling_Power | 20 Watts |
| Maximum_Temperature_Difference | 67 Degrees Celsius |
