PC10AG
Thermoelectric Cooler, 40 x 40 x 3.3mm, 10A, Qmax 60W, Delta Tmax 70°C
Manufacturer:
LAIRD Connectivity (now Ezurio)Sub Category:
RF & Wireless Components
Datasheet
PC10AG Datasheet
Product Description
The PC10AG thermoelectric cooler, manufactured by LAIRD CONNECTIVITY (NOW EZURIO), is a compact and powerful TEC designed for demanding thermal management applications. Available from Supreme Components International, an authorised distributor, this TEC offers exceptional cooling performance in a small form factor. With dimensions of 40 x 40 x 3.3mm, it's suitable for integration into various systems. Key specifications include a 10A current rating, a maximum heat pumping capacity (Qmax) of 60W, and a maximum temperature difference (Delta Tmax) of 70°C. The PC10AG is ideal for applications such as laser diode cooling, portable refrigerators, and temperature stabilization of electronic components. Trust Supreme Components International for genuine LAIRD CONNECTIVITY (NOW EZURIO) products and expert support.
Technical Specifications
| Attribute | Description |
|---|---|
| Weight_Grams | 35 |
| Configuration | 1-STAGE |
| Width_Millimeters | 40 |
| Height_Millimeters | 3.3 |
| Length_Millimeters | 40 |
| Maximum_Current_Amperes | 10 |
| Wire_Length_Millimeters | 152 |
| Hot_Side_Temperature_Celsius | 25 |
| Maximum_Heat_Pumping_Capacity_Watts | 60 |
| Maximum_Temperature_Difference_Celsius | 70 |
Ordering Information
| Attribute | Description |
|---|---|
| WEIGHT | 35 G |
| Packaging Type | TRAY |
