OD9238-24MBVXE
DC Fan, 92x38mm, 24VDC, Ball Bearing, Auto Restart
Datasheet
OD9238-24MBVXE Datasheet
Product Description
The Orion Fans OD9238-24MBVXE is a high-performance DC fan designed for diverse applications requiring effective cooling solutions. With dimensions of 92x38mm, this fan operates at 24VDC, ensuring optimal airflow in compact spaces. It incorporates a durable ball bearing system, enhancing its longevity and reliability. The auto-restart feature provides added convenience and safety in case of power disruptions. As an authorised distributor, Supreme Components International offers this top-tier fan, ensuring you receive quality and efficiency in every unit. Ideal for industrial and commercial use, trust in Orion Fans for your cooling needs.
Technical Specifications
| Attribute | Description |
|---|---|
| Voltage | 24 Volts DC |
| Air Flow | 85 Cubic Feet per Minute |
| Fan Size | 92 millimeters x 92 millimeters x 38 millimeters |
| Fan Speed | 3500 Revolutions Per Minute |
| Noise Level | 45 Decibels |
| Bearing Type | Ball Bearing |
| Connection Type | Wire Leads |
| Static Pressure | 0.28 Inches of Water |
| Special Features | Automatic Restart |
| Power Consumption | 3.6 Watts |
