Manufacturer Part Number (MPN) MP-2501A
Manufacturer SAME SKY (formerly CUI Devices)
Short Description Electret Condenser Microphone, Omnidirectional, -44dB, 20Hz-20kHz, 2.2kOhm, Through Hole
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of SAME SKY (formerly CUI Devices). We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Impedance
2.2 kOhms
Dimensions
9.7mm Diameter x 6.7mm Height
Sensitivity
-44dB ±3dB
Polar Pattern
Omnidirectional
Microphone Type
Electret Condenser
Operating Voltage
1.5V to 10V DC
Termination Style
Through Hole
Frequency Response
20Hz to 20kHz
Current Consumption
0.5mA maximum
Storage Temperature
-40°C to +85°C
Operating Temperature
-20°C to +70°C
Signal To Noise Ratio
60dB minimum
Standard Operating Voltage
4.5V DC

Full Description

The SAME SKY MP-2501A is a high-performance electret condenser microphone, available at Supreme Components International, an authorised distributor. This omnidirectional microphone is designed for clear and accurate audio capture across a wide range of frequencies. With a sensitivity of -44dB, it effectively picks up sound while minimizing noise. Its frequency response of 20Hz to 20kHz ensures that both low and high frequencies are accurately reproduced. The 2.2kOhm impedance makes it compatible with a variety of audio circuits. The through-hole mounting style provides a secure and stable connection. Ideal for applications such as voice recorders, audio sensors, communication devices, and other audio-related projects. Trust Supreme Components International for genuine SAME SKY components and reliable performance.
