MGBIC-BX10-D-C

Manufacturer Part Number (MPN) MGBIC-BX10-D-C
Manufacturer ATGBICS
Short Description 10GBASE-BX10-D SFP+ transceiver, 1330nm/1270nm, 10km reach, with DOM support.
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of ATGBICS. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Reach
10 kilometers
Data Rate
10 Gigabits per second
Fiber Type
Single Mode Fiber
Wavelength
1330 nanometers transmit / 1270 nanometers receive
Connector Type
LC
Transmit Power
Between -3 and 2 dBm
Power Consumption
Less than 1.5 Watts
Receive Sensitivity
Less than -14 dBm
Operating Temperature
0 degrees Celsius to 70 degrees Celsius
Digital Optical Monitoring Support
Yes

Full Description

The Approved Technology MGBIC-BX10-D-C is a high-performance 10GBASE-BX10-D SFP+ transceiver designed for single-mode fiber optic networks. Operating at wavelengths of 1330nm (transmit) and 1270nm (receive), this transceiver enables bidirectional communication over a single fiber strand, maximizing fiber utilization. It supports data transfer rates of up to 10Gbps and reaches distances of up to 10 kilometers. The MGBIC-BX10-D-C incorporates Digital Optical Monitoring (DOM) functionality, providing real-time monitoring of critical parameters such as optical power, temperature, and voltage. As an authorised distributor of Approved Technology, Supreme Components International guarantees the authenticity and quality of this transceiver. This SFP+ module is ideal for various applications, including data centers, enterprise networks, and telecommunications infrastructure.
