Reference Only
KSH30A20
Product Specification / Drawing: https://ele.kyocera.com/assets/products/power-semicon/specification/KSH30A20-file.pdf; SPICE: ; Environmental data: ; Series: TK; AEC-Q: ; Outline No.: TO-247 2pin; VRRM [V]: 200; Io [A]: 30.0; IFSM [A]: 300.0; IR [mA]: 0.500; VFM [V]: 0.95; @IFM [A]: 30.0; Operating Temperature Range (Min.): -40; Operating Temperature Range (Max.): 150; Circuit: Single; Rth(j-c) [°C/W]: 1.30; Connection type: I; Remarks: Low-IR type; RoHS Compliance: Yes; Weight: 5.500; Packaging style: Tube; Quantity per Package: 25; Recommended Substitute:
Manufacturer:
KyoceraCategory:
Discrete Semiconductors, Integrated Circuits (ics), Optoelectronics
Sub Category:
Other
Product Description
Product Specification / Drawing: https://ele.kyocera.com/assets/products/power-semicon/specification/KSH30A20-file.pdf; SPICE: ; Environmental data: ; Series: TK; AEC-Q: ; Outline No.: TO-247 2pin; VRRM [V]: 200; Io [A]: 30.0; IFSM [A]: 300.0; IR [mA]: 0.500; VFM [V]: 0.95; @IFM [A]: 30.0; Operating Temperature Range (Min.): -40; Operating Temperature Range (Max.): 150; Circuit: Single; Rth(j-c) [°C/W]: 1.30; Connection type: I; Remarks: Low-IR type; RoHS Compliance: Yes; Weight: 5.500; Packaging style: Tube; Quantity per Package: 25; Recommended Substitute:
