JNG
Metallized polypropylene film capacitor.
Datasheet
JNG Datasheet
Product Description
Supreme Components International, an authorised distributor of electronic components, presents the JNG series metallized polypropylene film capacitor from JB Capacitors. This capacitor is designed for applications demanding high stability and reliability. The JNG series features a metallized polypropylene film dielectric, ensuring low losses and excellent self-healing properties. It is well-suited for use in filtering, coupling, decoupling, and timing circuits. Its robust construction and consistent electrical characteristics make it a dependable choice for demanding applications. Choose Supreme Components International for guaranteed authenticity and quality components.
Technical Specifications
| Attribute | Description |
|---|---|
| Lead_Spacing | 5 millimeters to 31.5 millimeters |
| Voltage_Rating | 100 Volts Direct Current to 630 Volts Direct Current |
| Capacitance_Range | 0.001 microfarads to 10 microfarads |
| Climatic_Category | 40/85/21 |
| Dissipation_Factor | Less than or equal to 0.1 percent at 1 Kilohertz |
| Capacitance_Tolerance | Plus or minus 5 percent, Plus or minus 10 percent |
| Insulation_Resistance | Greater than or equal to 15000 Megaohms (Capacitance less than or equal to 0.33 microfarads), Greater than or equal to 5000 Seconds (Capacitance greater than 0.33 microfarads) |
| Operating_Temperature | -40 degrees Celsius to +85 degrees Celsius |
Ordering Information
| Attribute | Description |
|---|---|
| Packaging Type | BULK |
