JD120B-C

Manufacturer Part Number (MPN) JD120B-C
Manufacturer ATGBICS
Short Description 10GBASE-LR SFP+ Transceiver, 1310nm, 10km, SMF
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of ATGBICS. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Reach
10 kilometers
Data Rate
10 Gigabits per second
Fiber Type
Single Mode Fiber
Wavelength
1310 nanometers
Connector Type
LC
Transmit Power
Between -8.2 and 0.5 dBm
Power Consumption
Less than 1 Watt
Receive Sensitivity
Less than -11.1 dBm
Operating Temperature
0 to 70 degrees Celsius
Digital Diagnostics Monitoring
Yes

Full Description

The Approved Technology JD120B-C is a 10GBASE-LR SFP+ transceiver module, engineered for high-speed data transmission over single-mode fiber (SMF). Operating at a wavelength of 1310nm, this transceiver supports link lengths of up to 10 kilometers. It is fully compliant with the SFP+ MSA, ensuring compatibility with a wide range of networking equipment. The JD120B-C is designed for applications such as 10 Gigabit Ethernet, data centers, enterprise networking, and service provider infrastructure. Its low power consumption and compact form factor make it an excellent choice for high-density deployments. Supreme Components International is an authorised distributor of Approved Technology, guaranteeing authentic products and comprehensive support. This SFP+ transceiver offers a cost-effective solution for upgrading network capacity and improving performance.
