Manufacturer Part Number (MPN) IA-MS6335B
Manufacturer --SAME SKY (formerly CUI Devices)
Short Description Electret Condenser Microphone, Omnidirectional
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of --SAME SKY (formerly CUI Devices). We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Impedance
2200 Ohm
Dimensions
6.0 millimeters x 3.35 millimeters
Sensitivity
-42 decibels plus or minus 3 decibels
Polar Pattern
Omnidirectional
Microphone Type
Electret Condenser
Operating Voltage
1.5 Volts to 10 Volts
Termination Style
Solder Pads
Frequency Response
20 Hertz to 20000 Hertz
Current Consumption
Maximum 0.5 milliamperes
Storage Temperature
-40 degrees Celsius to +85 degrees Celsius
Operating Temperature
-20 degrees Celsius to +70 degrees Celsius
Signal To Noise Ratio
Minimum 60 decibels
Standard Operating Voltage
4.5 Volts

Full Description

The SAME SKY IA-MS6335B is a reliable electret condenser microphone designed for versatile audio recording. Supreme Components International, an authorised distributor, provides this omnidirectional microphone, ensuring consistent sound pickup from all directions. Its key specifications include a -42dB sensitivity, a 2.2kOhm impedance, and a wide frequency response ranging from 20Hz to 20kHz. This microphone is suitable for applications such as voice recording, audio monitoring, and communication devices. Benefit from its compact size and excellent performance for your audio needs. As an authorised distributor, Supreme Components International guarantees the authenticity and quality of this SAME SKY microphone.
