IA-MM2535
Supreme Components International, an authorised distributor, presents the IA-MM2535 electret condenser microphone from SAME SKY. This omnidirectional microphone is designed for superior audio capture with a sensitivity of -42dB ±3dB and a signal-to-noise ratio of 62dB. Its 2.2kOhm impedance ensures compatibility with a wide range of audio circuits. The IA-MM2535 features convenient solder pad connections for secure and easy installation. This microphone is perfect for applications requiring clear and accurate sound reproduction, such as voice recorders, audio sensors, and communication devices. Benefit from SAME SKY's quality and Supreme Components International's reliable distribution.
Specifications
| Parameter | Value |
|---|---|
| height | 3.5 millimeters |
| diameter | 2.5 millimeters |
| impedance | 2.2 kiloohms |
| output_type | Analog |
| sensitivity | -42 decibels plus or minus 3 decibels |
| polar_pattern | Omnidirectional |
| voltage_rating | 1.5 volts to 10 volts |
| frequency_range | 20 hertz to 20 kilohertz |
| microphone_type | Electret Condenser |
| termination_style | Solder Pad |
| current_consumption | 500 microamperes |
| operating_temperature | -20 degrees Celsius to 70 degrees Celsius |
| signal_to_noise_ratio | 62 decibels |
