HF05-1A54-9
Reed Relay, 1 Form A, 5V Coil, 0.5A, 200V
PRODUCT DETAILS
Product Description
The HF05-1A54-9 Reed Relay from STANDEX MEDER, available at Supreme Components International, an authorised distributor, is a versatile and dependable solution for your switching needs. This relay features a 1 Form A (SPST-NO) contact configuration, ensuring reliable signal transmission. It operates with a 5V coil voltage and can switch up to 0.5A at 200V. The reed relay design offers excellent isolation and long operational life.
Ideal for applications requiring fast switching speeds and low power consumption, the HF05-1A54-9 is suitable for use in telecommunications equipment, automatic test equipment (ATE), instrumentation, and various industrial control systems. Its compact size allows for easy integration into densely populated circuit boards. Trust Supreme Components International for genuine STANDEX MEDER components and expert support.
Product Tags
Technical Specifications
| Coil voltage | 5 Volts |
|---|---|
| Package type | Single In-Line Package |
| Release time | 0.1 Milliseconds |
| Mounting style | Through Hole |
| Operating time | 0.5 Milliseconds |
| Coil resistance | 500 Ohms |
| Insulation voltage | 1500 Volts DC |
| Contact power rating | 10 Watts |
| Contact configuration | Single Pole Single Throw Normally Open |
| Maximum switching current | 0.5 Amperes |
| Maximum switching voltage | 200 Volts |
