FMS2307-H
P-Channel MOSFET, -30V, -6.5A, SOP-8
PRODUCT DETAILS
Product Description
Supreme Components International, an authorised distributor, presents the FMS2307-H, a high-quality P-Channel MOSFET manufactured by FORMOSA MICROSEMI. This MOSFET is designed for a variety of applications requiring efficient power switching and management. Key features include a -30V drain-source voltage and a -6.5A continuous drain current. The FMS2307-H comes in a space-saving SOP-8 package, making it suitable for compact designs. Its P-Channel configuration simplifies drive circuitry in many applications. Benefit from FORMOSA MICROSEMI's renowned reliability and performance with this versatile MOSFET. Trust Supreme Components International for genuine components and expert support.
Product Tags
Technical Specifications
| Current | -6.5 Amperes |
|---|---|
| Voltage | -30 Volts |
| Gate charge | 12 nano Coulombs at -4.5 Volts |
| Channel type | P-Channel |
| Package type | Small Outline Package 8 Leads |
| Mounting style | Surface Mount Technology |
| Power dissipation | 2.5 Watts |
| Drain source resistance | 28 milli Ohms at Gate-Source Voltage of -10 Volts |
Ordering Information
| Packaging Type | Tape And Reel |
|---|
