EK-23024-C64
The EK-23024-C64 is a high-performance, non-isolated DC-DC converter module from AATC. It offers efficient power conversion for various applications.
Manufacturer:
AATCSub Category:
OTHER
Datasheet
EK-23024-C64 Datasheet
Product Description
Supreme Components International, an authorised distributor, presents the EK-23024-C64, a high-performance DC-DC converter module manufactured by Advanced Analog Technology Corp (AATC). This non-isolated module provides a stable 3.3V output with a maximum current of 4A. Its input voltage range spans from 4.5V to 24V, offering flexibility in various power supply designs. The EK-23024-C64 boasts high efficiency, minimizing energy loss and heat generation. Integrated protection features safeguard against overcurrent, overvoltage, and short circuits, ensuring reliable operation. Ideal for applications requiring a compact and efficient DC-DC conversion solution.
Technical Specifications
| Attribute | Description |
|---|---|
| Dimensions | 22.86 millimeters x 12.7 millimeters x 8.5 millimeters |
| Efficiency | Up to 95 percent |
| Package Type | SIP Module |
| Output Current | 4 Amperes |
| Output Voltage | 3.3 Volts |
| Input Voltage Range | 4.5 Volts to 24 Volts |
| Protection Features | Over Current Protection, Over Temperature Protection, Under Voltage Lockout |
| Switching Frequency | 500 kilohertz |
| Operating Temperature Range | -40 degrees Celsius to +85 degrees Celsius |
Ordering Information
| Attribute | Description |
|---|---|
| MPQ | 1 |
| Packaging Type | BULK |
