E1MG-LHA-C

Manufacturer Part Number (MPN) E1MG-LHA-C
Manufacturer ATGBICS
Short Description 10GBASE-LR SFP+ transceiver, 1310nm, 10km, LC connector

Supreme Components is an authorized distributor of ATGBICS. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Reach
10 kilometers
Data Rate
10 Gigabits per second
Fiber Type
Single Mode Fiber
Wavelength
1310 nanometers
Connector Type
LC
Transmit Power
Between -8.2 and 0.5 dBm
Power Consumption
Less than 1 Watt
Receive Sensitivity
Less than -11.1 dBm
Operating Temperature
0 to 70 degrees Celsius
Digital Diagnostics Monitoring Or Digital Optical Monitoring
Yes

Full Description

Supreme Components International, an authorised distributor, presents the APPROVED TECHNOLOGY E1MG-LHA-C, a 10GBASE-LR SFP+ transceiver engineered for high-speed data transmission over single-mode fiber. Operating at a wavelength of 1310nm, this module enables reliable connectivity up to 10 kilometers. The E1MG-LHA-C features a duplex LC connector for easy integration into existing network infrastructure. This SFP+ transceiver is compliant with industry standards, ensuring seamless interoperability with a wide range of networking equipment. It is a cost-effective solution for upgrading network capacity in data centers, enterprise environments, and service provider networks, providing a stable and efficient 10 Gigabit Ethernet connection.
