DSO751SBM
7.5 x 5 mm SMD Crystal Oscillator by KDS Daishinku
Datasheet
DSO751SBM Datasheet
Product Description
The DSO751SBM from KDS Daishinku is a surface-mount (SMD) crystal oscillator designed for applications requiring a stable and accurate frequency source. With dimensions of 7.5 x 5 mm, this compact oscillator is suitable for space-constrained designs. Supreme Components International is an authorised distributor of KDS Daishinku components, guaranteeing the authenticity and quality of this product. Crystal oscillators like the DSO751SBM are essential components in various electronic devices, including microcontrollers, communication systems, and timing circuits. Its robust design ensures reliable performance across a wide range of operating conditions. Choose the DSO751SBM for your next project and experience the precision and stability of KDS Daishinku crystal oscillators.
Technical Specifications
| Attribute | Description |
|---|---|
| Aging | Plus or minus 3 parts per million per year |
| Package | Surface Mount Device 7.5 millimeters by 5 millimeters |
| Output Type | HCMOS |
| Supply Voltage | 1.8 Volts, 2.5 Volts, 3.3 Volts |
| Frequency Range | 1.5 Megahertz to 80 Megahertz |
| Frequency Stability | Plus or minus 100 parts per million |
| Frequency Tolerance | Plus or minus 50 parts per million |
| Storage Temperature | Negative 40 degrees Celsius to Positive 85 degrees Celsius |
| Operating Temperature | Negative 20 degrees Celsius to Positive 70 degrees Celsius |
Ordering Information
| Attribute | Description |
|---|---|
| Packaging Type | Tape And Reel |
