| Manufacturer Part Number (MPN) | DS04-254-1S-01BK |
| Manufacturer | Same Sky (formerly CUI Devices) |
| Short Description | 1 Position, Through Hole, 2.54 mm Pitch, Raised Slide Actuator, Flat Bottom, Short Pin, DIP Switch |
Request for Quotation
Supreme Components is an authorized distributor of Same Sky (formerly CUI Devices). We do not carry stock of this item but can quote upon request. Submit your request using the form.
Product Attributes
TYPE
DESCRIPTION
Category
Actuator Level
Raised
Actuator Type
Slide
Bottom
Flat
Cap
No
Dimensions Lxwxh (in)
0.14 x 0.24 x 0.14
Dimensions Lxwxh (mm)
3.54 x 6.2 x 3.66
Height (mm)
3.66
Length (mm)
3.54
Mounting Style
Through Hole
Non-switching Current Rating (ma)
100
Non-switching Voltage Rating (vdc)
50
Number Of Positions
1
Operating Temp Max (°c)
85
Operating Temp Min (°c)
-40
Orientation
Horizontal
Pin
Short
Pitch (mm)
2.54
Series
DS04-254
Switch Type
DIP
Switching Current Rating (ma)
25
Switching Voltage Rating (vdc)
24
Termination
PC Pin
Washable
No
Width (mm)
6.2
Full Description
1 Position, Through Hole, 2.54 mm Pitch, Raised Slide Actuator, Flat Bottom, Short Pin, DIP Switch
