DS01-254-L-12BE
12 Position, Through Hole, 2.54 mm Pitch, Raised Slide Actuator, Flat Bottom, Long Pin, DIP Switch
Product Category
Switches
Product Sub category
Dip/rotary switch
PRODUCT DETAILS
Product Description
12 Position, Through Hole, 2.54 mm Pitch, Raised Slide Actuator, Flat Bottom, Long Pin, DIP Switch
Product Tags
Technical Specifications
| Actuator level | Raised |
|---|---|
| Actuator type | Slide |
| Bottom | Flat |
| Cap | No |
| Dimensions lxwxh (in) | 1.26 x 0.39 x 0.21 |
| Dimensions lxwxh (mm) | 31.9 x 9.9 x 5.35 |
| Height (mm) | 5.35 |
| Length (mm) | 31.9 |
| Mounting style | Through Hole |
| Non-switching current rating (ma) | 100 |
| Non-switching voltage rating (vdc) | 50 |
| Number of positions | 12 |
| Operating temp max (°c) | 85 |
| Operating temp min (°c) | -40 |
| Orientation | Horizontal |
| Pin | Long |
| Pitch (mm) | 2.54 |
| Series | DS01-254 |
| Switch type | DIP |
| Switching current rating (ma) | 25 |
| Switching voltage rating (vdc) | 24 |
| Termination | PC Pin |
| Washable | No |
| Width (mm) | 9.9 |
