DIP05-1A66-13L
Reed Switch, SPST, Normally Open (NO), 200V, 0.5A, DIP
Datasheet
DIP05-1A66-13L Datasheet
Product Description
Supreme Components International, an authorised distributor, presents the DIP05-1A66-13L Reed Switch from Standex Meder. This high-quality reed switch features a Single Pole Single Throw (SPST) configuration and is Normally Open (NO). It's designed for applications requiring reliable switching, with a voltage rating of 200V and a current rating of 0.5A. The DIP package allows for easy integration into circuit boards. Reed switches are known for their long life, high reliability, and fast switching speeds. This particular model is suitable for a wide range of applications, including proximity sensing, security systems, and instrumentation. Trust Supreme Components International for genuine Standex Meder components and expert support.
Technical Specifications
| Attribute | Description |
|---|---|
| Package_Type | Dual Inline Package |
| Mounting_Style | Through Hole |
| Number_Of_Pins | 2 |
| Typical_Operate_Time | 0.5 milliseconds |
| Typical_Release_Time | 0.1 milliseconds |
| Contact_Configuration | Single Pole Single Throw Normally Open |
| Maximum_Carry_Current | 1 Ampere |
| Maximum_Switching_Current | 0.5 Ampere |
| Maximum_Switching_Voltage | 200 Volts |
| Operating_Temperature_Range | -40 degrees Celsius to +125 degrees Celsius |
