DEP1-5-D3-M
1W isolated DC-DC converter from CUI, featuring a 5V input and an unregulated 3.3V single output. Ideal for space-constrained applications.
Brand
Product Category
DC-DC CONVERTERS
Product Sub category
Isolated
SKU
6556ae07ad9b
MPQ
1
Packaging Type
Bulk
PRODUCT DETAILS
Product Description
The DEP1-5-D3-M is a 1W isolated DC-DC converter manufactured by CUI (Bel Fuse). Supreme Components International is an authorized distributor of CUI products. This converter is designed for applications requiring isolation and efficient power conversion. It features an unregulated single output, accepting a 5V input voltage and providing a stable 3.3V output voltage. The compact SIP package allows for easy integration into various circuit boards and systems. This DC-DC converter is suitable for a wide range of applications, including industrial control, instrumentation, and telecommunications equipment. Its isolated design ensures safety and reliability in demanding environments. The unregulated output provides a cost-effective solution for applications where precise voltage regulation is not critical.
Product Tags
Technical Specifications
| Dimensions | 19.5 millimeters x 6.0 millimeters x 9.5 millimeters |
|---|---|
| Efficiency | 70 percent |
| Package type | Single In-Line Package |
| Power rating | 1 Watt |
| Mounting type | Through Hole |
| Isolation type | Isolated |
| Line regulation | Plus or Minus 1.2 percent |
| Load regulation | Plus or Minus 1.2 percent |
| Regulation type | Unregulated |
| Ripple and noise | 100 millivolts peak-to-peak |
| Isolation voltage | 1500 Volts DC |
| Number of outputs | 1 |
| Input voltage range | 4.5 Volts DC to 5.5 Volts DC |
| Nominal input voltage | 5 Volts DC |
| Maximum output current | 303 milliamperes |
| Nominal output voltage | 3.3 Volts DC |
| Maximum operating temperature | 105 degrees Celsius |
| Minimum operating temperature | -40 degrees Celsius |
Ordering Information
| Mpq | 1 |
|---|---|
| Weight | 2.5 G |
| Packaging Type | Bulk |
