CBL-UA3-UA3-15GP
Cable, USB, 1500 mm, Type A 3.0 to Type C 3.0, 28 AWG, PVC, Gray
Product Description
Cable, USB, 1500 mm, Type A 3.0 to Type C 3.0, 28 AWG, PVC, Gray
Technical Specifications
| Attribute | Description |
|---|---|
| Cable Length (mm) | 1500 |
| Cable Style | Round |
| Color | Gray |
| Connector 1 | Type A Plug |
| Connector 2 | Type A Plug |
| Current Rating (A) | 1.5 |
| IP Rating | No IP Rating |
| Jacket Material | PVC |
| Operating Temp MAX (°C) | 80 |
| Operating Temp MIN (°C) | -20 |
| Series | CBL-UA3-UA3 |
| Shielding | Yes |
| USB Standard | USB 3.2 Gen 1 |
| Voltage Rating (Vdc) | 30 |
| Wire Diameter (mm) | 5.5 |
| Wire Gauge (AWG) | 28 |
