CAF-A225S-118-300
AC fan, 120 x 120 x 25 mm, 100 ~ 125 V, sleeve, 1800 RPM, 50 CFM
Manufacturer:
Same Sky (formerly CUI Devices)Category:
Thermal Management
Sub Category:
Fans & Blowers
Product Description
AC fan, 120 x 120 x 25 mm, 100 ~ 125 V, sleeve, 1800 RPM, 50 CFM
Technical Specifications
| Attribute | Description |
|---|---|
| Air Flow at 50Hz (CFM) | 44.69 |
| Air Flow at 60Hz (CFM) | 45.5 |
| Bearing Type | Sleeve |
| Current Rating at 50Hz (mA) | 130 |
| Current Rating at 60Hz (mA) | 120 |
| Dimensions LxWxH (in) | 4.72 x 4.72 x 0.98 |
| Dimensions LxWxH (mm) | 120 x 120 x 25 |
| Fan Type | Axial Fan |
| Height (mm) | 25 |
| Length (mm) | 120 |
| Max Input Current (mA) | 160 |
| Noise at 50Hz (dBA) | 32.6 |
| Noise at 60Hz (dBA) | 35.2 |
| Operating Temp MAX (°C) | 70 |
| Operating Temp MIN (°C) | -10 |
| Operating Voltage (Vdc) | 100 ~ 125 |
| PWM Control Signal | No |
| Rated Power at 50Hz (W) | 12.7 |
| Rated Power at 60Hz (W) | 10.8 |
| Rated Speed at 50Hz (RPM) | 1800 |
| Rated Speed at 60Hz (RPM) | 1700 |
| Rotation Detector | No |
| Series | CAF-A2S |
| Static Pressure at 50Hz (inH2O) | 0.08 |
| Static Pressure at 60Hz (inH2O) | 0.08 |
| Tachometer Signal | No |
| Voltage Rating (Vac) | 110 |
| Width (mm) | 120 |
