BC559B
PNP Bipolar Transistor, 30V, 100mA, TO-92
Datasheet
BC559B Datasheet
Product Description
The BC559B is a versatile PNP bipolar transistor from DIOTEC, available at Supreme Components International, your authorised distributor for electronic components. This transistor is housed in a TO-92 package and is well-suited for a wide range of applications, including amplification and switching circuits. Its key specifications include a collector-emitter voltage (Vceo) of 30V and a collector current (Ic) of 100mA. The BC559B offers excellent performance characteristics, making it a popular choice for both hobbyists and professional engineers. Its compact size and ease of use make it ideal for prototyping and small-scale production runs. Trust Supreme Components International for genuine DIOTEC components and reliable service.
Technical Specifications
| Attribute | Description |
|---|---|
| Package_Type | TO-92 |
| Dc_Current_Gain | 200 to 450 |
| Transistor_Polarity | PNP |
| Transition_Frequency | 100 megahertz |
| Collector_Current_Maximum | 100 milliamperes |
| Power_Dissipation_Maximum | 500 milliwatts |
| Maximum_Operating_Temperature | 150 degrees Celsius |
| Collector_Emitter_Voltage_Maximum | 30 volts |
