Reference Only
AS229704TN1
Khatod PL1161 Lens, TIR, Total Internal Reflection, 22mm Diameter, 9.7mm Height, Clear
Datasheet
AS229704TN1 Datasheet
Product Description
Supreme Components International, an authorised distributor, presents the Khatod AS229704TN1, a precision-engineered TIR (Total Internal Reflection) lens. This PL1161 lens boasts a 22mm diameter and a 9.7mm height, crafted from high-quality clear material for superior optical performance. TIR lenses like the AS229704TN1 utilize total internal reflection to efficiently collimate light, minimizing light loss and maximizing intensity. Ideal for LED lighting, spot lighting, and other applications requiring precise light control. Khatod is a leading manufacturer of optics, and this lens exemplifies their commitment to quality and innovation. Choose Supreme Components International for genuine Khatod components and expert support.
Technical Specifications
| Attribute | Description |
|---|---|
| Color | Clear |
| Material | Polymethyl Methacrylate (PMMA) |
| Lens_Type | Total Internal Reflection (TIR) |
| Application | High Bay, Low Bay, General Lighting, Indoor |
| Lens_Height | 9.7 millimeters |
| Lens_Diameter | 22 millimeters |
| Mounting_Type | Holder |
| Typical_Beam_Angle | Varies with LED |
