AFBR-57R5AEZ-BR1-C

Manufacturer Part Number (MPN) AFBR-57R5AEZ-BR1-C
Manufacturer ATGBICS
Short Description 10GBASE-LR SFP+ transceiver, 1310nm, 10km reach
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of ATGBICS. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Data Rate
10.3125 GigabitsPerSecond
Fiber Type
SingleModeFiber
Wavelength
1310 nanometers
Application
10GBASE-LR
Maximum Reach
10 kilometers
Connector Type
LC
Operating Voltage
3.3 Volts
Operating Temperature Range
0 degrees Celsius to 70 degrees Celsius
Digital Diagnostics Monitoring
Yes

Full Description

Supreme Components International, an authorised distributor, presents the Approved Technology AFBR-57R5AEZ-BR1-C, a 10GBASE-LR SFP+ transceiver designed for high-speed data transmission. This optical module operates at a wavelength of 1310nm and supports a link length of up to 10 kilometers over single-mode fiber (SMF). It is compliant with the SFP+ MSA and IEEE 802.3ae 10GBASE-LR standards. The AFBR-57R5AEZ-BR1-C is suitable for various applications, including 10 Gigabit Ethernet, data centers, and enterprise networking environments. Its hot-pluggable design allows for easy installation and replacement. Benefit from reliable performance and extended reach with this Approved Technology SFP+ transceiver.
