AC-C7-R UK
Manufacturer SAME SKY (formerly CUI Devices)
Short Description Electret Condenser Microphone, Omnidirectional, -42dB ±3dB, 20Hz~20kHz, 2.2kΩ, 2V, Through Hole
Datasheet 📄 Datasheet

Product Attributes

TYPE
DESCRIPTION
Impedance
2200 Ohms
Sensitivity
-42 decibels plus or minus 3 decibels
Directionality
Omnidirectional
Frequency Range
20 Hertz to 20000 Hertz
Microphone Type
Electret Condenser Microphone
Operating Voltage
2 Volts
Termination Style
Through Hole
Current Consumption
0.5 Milliamps
Storage Temperature
-40 Degrees Celsius to +85 Degrees Celsius
Operating Temperature
-20 Degrees Celsius to +70 Degrees Celsius
Signal To Noise Ratio
60 decibels
Maximum Supply Voltage
10 Volts
Minimum Supply Voltage
1.5 Volts

Full Description

The SAME SKY AC-C7-R UK is a versatile electret condenser microphone designed for a wide range of audio recording and amplification applications. Supreme Components International, an authorised distributor, provides this microphone known for its omnidirectional pickup pattern, capturing sound from all directions with equal sensitivity. Its key specifications include a sensitivity of -42dB ±3dB, ensuring clear and accurate audio capture. The microphone's frequency response spans from 20Hz to 20kHz, covering the entire audible spectrum. With a 2.2kΩ impedance and a 2V operating voltage, it's compatible with various audio circuits. The through-hole mounting style simplifies integration into existing designs. This microphone is a reliable choice for projects requiring high-quality audio input.
