AC-C7 NA
Manufacturer SAME SKY (formerly CUI Devices)
Short Description Electret Condenser Microphone, Omnidirectional, -42dB
Datasheet 📄 Datasheet

Product Attributes

TYPE
DESCRIPTION
Impedance
2.2 kOhm
Dimensions
Diameter 9.7 mm x 6.7 mm
Sensitivity
-42dB +/- 3dB
Polarpattern
Omnidirectional
Microphonetype
Electret Condenser
Operatingvoltage
1.5V to 10V
Terminationstyle
Pin
Frequencyresponse
20Hz to 20kHz
Currentconsumption
Maximum 0.5mA
Signaltonoiseratio
Minimum 60dB
Storagetemperature
-40 degrees Celsius to +85 degrees Celsius
Operatingtemperature
-20 degrees Celsius to +70 degrees Celsius
Standardoperatingvoltage
4.5V

Full Description

The SAME SKY AC-C7 NA is a reliable omnidirectional electret condenser microphone suitable for a wide range of audio recording and communication needs. Supreme Components International is an authorised distributor of SAME SKY products, ensuring you receive genuine components. This microphone boasts a sensitivity of -42dB, making it highly responsive to sound. Its 2.2kOhm impedance and broad 20Hz-20kHz frequency response guarantee excellent audio fidelity. The omnidirectional polar pattern captures sound evenly from all directions, making it ideal for group recordings or situations where the sound source is not always directly in front of the microphone. Applications include voice recording, conferencing, and audio monitoring. Trust Supreme Components International for your audio component needs.
