Manufacturer Part Number (MPN) AC-C7 JP
Manufacturer SAME SKY (formerly CUI Devices)
Short Description Electret Condenser Microphone, Omni-Directional, -42dB
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of SAME SKY (formerly CUI Devices). We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Impedance
2.2kOhm
Dimensions
9.7mm Diameter x 6.7mm Height
Sensitivity
-42dB ±3dB
Directionality
Omni-Directional
Frequency Range
20Hz ~ 20kHz
Microphone Type
Electret Condenser Microphone
Operating Voltage
1.5V ~ 10V
Termination Style
Pin
Current Consumption
0.5mA maximum
Signal To Noise Ratio
58dB minimum
Standard Operating Voltage
4.5V

Full Description

The SAME SKY AC-C7 JP is a high-performance Electret Condenser Microphone designed for superior audio capture. As an authorised distributor, Supreme Components International guarantees the authenticity and quality of this component. Its Omni-Directional polar pattern ensures consistent sound pickup from all directions, making it suitable for diverse recording environments. With a sensitivity of -42dB and an impedance of 2.2kOhm, this microphone delivers clear and detailed audio. The wide frequency response of 20Hz-20kHz captures a full range of sound, ensuring accurate reproduction. Ideal for voice recording, instrument miking, and other audio applications, the AC-C7 JP offers exceptional performance and reliability.
