AC-C5-L-W NA

DC Power Connector, 2.1 mm ID, 5.5 mm OD, Center Positive, Through Hole

The AC-C5-L-W NA DC power connector, manufactured by SAME SKY, is a crucial component for any electronic device requiring a stable DC power input. Available at Supreme Components International, an authorized distributor, this connector features a standard 2.1 mm inner diameter (ID) and a 5.5 mm outer diameter (OD), making it compatible with a wide range of power adapters. Its through-hole mounting style ensures a secure and robust connection to your PCB. Designed for center-positive polarity, this connector is commonly used in various applications, including consumer electronics, industrial equipment, and DIY projects. Trust Supreme Components International for genuine SAME SKY components and reliable performance.

Product Categories

Ac Power Cords Interconnect

Specifications

Parameter Value
Gender Jack
Polarity Center Positive
Durability 5000 Cycles
Mounting Type Through Hole
Current Rating 5 Amperes
Outer Diameter 5.5 Millimeters
Voltage Rating 24 Volts DC
Contact Plating Nickel
Insulator Color Black
Contact Material Brass
Termination Style Solder Lug
Insulator Material PBT
Center Pin Diameter 2.1 Millimeters
Operating Temperature -20 to +70 Degrees Celsius

Ordering Information

Parameter Value
Packaging Type BULK

Datasheet

Download Datasheet
