Manufacturer Part Number (MPN) AC-C5-L NA
Manufacturer SAME SKY (formerly CUI Devices)
Short Description Electret Condenser Microphone, Omnidirectional, -42dB, 2.2kOhm, 20Hz-20kHz
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of SAME SKY (formerly CUI Devices). We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Impedance
2.2 kOhms
Dimensions
9.7 mm Diameter x 6.7 mm Height
Sensitivity
-42dB ±3dB
Polar Pattern
Omnidirectional
Microphone Type
Electret Condenser
Operating Voltage
1.5 Volts to 10 Volts
Termination Style
Pin
Frequency Response
20 Hertz to 20 Kilohertz
Current Consumption
Maximum 0.5 mA
Storage Temperature
-40 Degrees Celsius to +85 Degrees Celsius
Operating Temperature
-20 Degrees Celsius to +70 Degrees Celsius
Signal To Noise Ratio
Minimum 60 dB
Standard Operating Voltage
2 Volts

Full Description

Supreme Components International, an authorised distributor, presents the SAME SKY AC-C5-L NA, a high-quality electret condenser microphone. This omnidirectional microphone captures sound from all directions, providing a natural and balanced audio experience. With a sensitivity of -42dB and an impedance of 2.2kOhm, it delivers clear and crisp audio signals. Its broad frequency response, ranging from 20Hz to 20kHz, ensures accurate reproduction of a wide range of sounds. The AC-C5-L NA is suitable for various applications, including voice recording, conferencing, and audio monitoring. Trust Supreme Components International for reliable electronic components and exceptional customer service. Experience superior audio performance with the SAME SKY AC-C5-L NA.

Looking for more SAME SKY (formerly CUI Devices) connectors? [Click here to browse all SAME SKY (formerly CUI Devices) parts]

Supreme Components is an authorized distributor of SAME SKY (formerly CUI Devices). We do not carry stock of this item but can quote upon request. Submit your request using the form.
