61 03 001 2014

Manufacturer Part Number (MPN) 61 03 001 2014
Manufacturer Harting
Short Description HARTING Han 3A-STI-M-axial-M20, Male insert, axial screw termination, M20 cable gland
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Category
Wire Gauge
0.75 to 2.5 square millimeters
Cable Gland
M20
Mating Cycles
Greater than or equal to 500
Rated Current
16 Amperes
Rated Voltage
230 Volts
Contact Surface
Silver
Insert Material
Polycarbonate
Contact Material
Copper alloy
Pollution Degree
3
Termination Type
Axial screw termination
Tightening Torque
0.5 Newton meters
Contact Resistance
Less than or equal to 3 milliohms
Number Of Contacts
3 plus Protective Earth
Degree Of Protection
IP20 according to DIN EN 60529
Limiting Temperature
125 degrees Celsius
Insulation Resistance
Greater than 10 to the power of 10 Ohms
Rated Impulse Voltage
4 Kilovolts
Fire Protection Standard
HL3, R22 plus R23 according to EN 45545

Full Description

The HARTING 61030012014 is a robust Han 3A series male insert specifically engineered for heavy-duty power connector applications. This insert features axial screw termination, simplifying the wiring process and ensuring a secure and vibration-resistant connection. The integrated M20 cable gland provides strain relief and protects the cable from environmental factors. Supreme Components International is an authorised distributor of HARTING products, guaranteeing the authenticity and quality of this component. This male insert is ideal for use in industrial machinery, automation systems, and other demanding applications where reliable power transmission is critical. Its durable construction and ease of installation make it a cost-effective and dependable solution for your connectivity needs. Choose HARTING for superior performance and long-lasting reliability.
