61 03 001 1010 160

Manufacturer Part Number (MPN) 61 03 001 1010 160
Manufacturer Harting
Short Description HARTING Han 3A-STI-M-axial-M20, Male insert, axial screw termination, M20 cable gland
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Category
Gender
Male
Wire Gauge
0.2 to 2.5 square millimeters
Mating Cycles
Greater than or equal to 500
Rated Current
16 Amperes
Rated Voltage
230/400 Volts
Insert Material
Polycarbonate
Contact Material
Copper Alloy
Pollution Degree
3
Temperature Range
-40 to +125 degrees Celsius
Contact Resistance
Less than 3 milliOhms
Number Of Contacts
3 plus Protective Earth
Termination Method
Screw
Insulation Resistance
Greater than 10 to the power of 10 Ohms
Rated Impulse Voltage
4 kilovolts
Contact Surface Material
Silver
Flammability According To Ul94
V-0
Degree Of Protection According To Iec60529
IP20

Full Description

The HARTING 61030011010160 is a robust and reliable Han 3A-STI-M-axial-M20 male insert, specifically engineered for heavy-duty power connector applications. This connector features axial screw termination, providing a secure and vibration-resistant connection for power cables. The integrated M20 cable gland ensures proper cable sealing and strain relief, protecting the connection from environmental factors. Designed for use in harsh industrial environments, this HARTING connector is ideal for applications such as industrial machinery, automation systems, power distribution, and transportation. Supreme Components International is an authorised distributor of HARTING electronic components, ensuring you receive a genuine, high-quality product. This male insert is a crucial component for creating dependable and long-lasting power connections.
