Home Harting

33 58 231 0050 027

Manufacturer Part Number (MPN) 33 58 231 0050 027
Manufacturer Harting
Short Description HARTING Han 3A-STI-M-M20 - Male insert, screw termination, M20 cable gland
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Category
Gender
Male
Wire Gauge
0.75 to 2.5 square millimeters
Cable Gland
M20
Mating Cycles
Greater than or equal to 500
Rated Current
16 Amperes
Rated Voltage
230 Volts
Material Insert
Polycarbonate (PC)
Pollution Degree
3
Surface Contacts
Silver Plated
Material Contacts
Copper Alloy
Thermal Endurance
-40 to +125 degrees Celsius
Tightening Torque
0.5 Newton Meters
Contact Resistance
Less than 3 milliOhms
Number Of Contacts
3 plus Protective Earth
Termination Method
Screw
Insulation Resistance
Greater than 10 to the power of 10 Ohms
Rated Impulse Voltage
4 Kilovolts
Flammability According To Ul94
V-0
Degree Of Protection According To Iec60529
IP20

Full Description

The HARTING 33582310050027 is a robust Han 3A series male insert specifically engineered for demanding heavy-duty power connector applications. This insert features a reliable screw termination method, ensuring secure and long-lasting electrical connections. The integrated M20 cable gland provides strain relief and protection for the connected cable, enhancing the overall durability and reliability of the assembly. Supreme Components International is an authorised distributor of HARTING, guaranteeing you receive genuine, high-quality components. This male insert is ideal for use in industrial machinery, automation systems, and other applications where dependable power transmission is critical. Choose HARTING for superior performance and longevity.

Looking for more Harting connectors? [Click here to browse all Harting parts]

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.
