33 48 313 1805 010

Manufacturer Part Number (MPN) 33 48 313 1805 010
Manufacturer Harting
Short Description HARTING HAN 3A-STI-M-CR-M20, Male insert, crimp termination, M20 cable gland
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Category
Gender
Male
Wire Gauge
0.14 to 4 square millimeters
Locking Type
For Han A Hoods and Housings
Mating Cycles
Greater than or equal to 500
Rated Current
16 Amperes
Rated Voltage
230 Volts
Insert Material
Polycarbonate
Pollution Degree
3
Surface Contacts
Silver
Material Contacts
Copper Alloy
Contact Resistance
Less than 3 milliOhms
Number Of Contacts
3 plus Protective Earth
Termination Method
Crimp
Insulation Resistance
Greater than 10 to the power of 10 Ohms
Operation Temperature
-40 to +125 degrees Celsius
Rated Impulse Voltage
4 kilovolts
Flammability According To Ul94
V-0
Protection Degree According To Dinen60529
IP20

Full Description

Supreme Components International, an authorised distributor, presents the HARTING 33483131805010, a robust Han 3A series male insert specifically engineered for demanding heavy-duty power connector applications. This insert utilizes crimp termination, providing a secure and reliable electrical connection. The design incorporates an M20 cable gland, facilitating efficient cable management and offering excellent strain relief. This connector is well-suited for industrial environments where dependable power transmission is critical. The Han 3A series is known for its durability and performance, making it a preferred choice for various industrial applications. Trust Supreme Components International for your HARTING connector needs.
