33 01 412 0300 008

Manufacturer Part Number (MPN) 33 01 412 0300 008
Manufacturer Harting
Short Description HARTING Han 1A-STI-M-M20-SC-C, Male connector insert, M20 cable gland, Crimp termination, 3+PE contacts
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Category
Gender
Male
Series
Han 1A
Wire Gauge
0.14 to 2.5 square millimeters
Cable Gland
M20
Mating Cycles
Greater than or equal to 500
Rated Current
16 Amperes
Rated Voltage
50 Volts
Wire Gauge Awg
26 to 14 AWG
Nominal Current
16 Amperes
Nominal Voltage
50 Volts
Housing Material
Polyamide
Pollution Degree
3
Contact Resistance
Less than 3 milliOhms
Number Of Contacts
3 plus PE
Termination Method
Crimp
Insulation Resistance
Greater than 10 to the power of 10 Ohms
Operating Temperature
-30 to +80 degrees Celsius
Flammability Class According To Ul94
V-0
Protection Degree According To Iec60529
IP20

Full Description

The Harting 33014120300008 is a Han 1A-STI-M-M20-SC-C male connector insert, part of Harting's renowned Han 1A series. This rectangular connector is designed for industrial environments, providing a secure and reliable connection solution. It features a M20 cable gland, ensuring proper cable strain relief and protection against environmental factors. The crimp termination method simplifies wiring and ensures a strong electrical connection. With 3+PE (Protective Earth) contacts, this connector is suitable for power and signal transmission. Supreme Components International is an authorised distributor of Harting, guaranteeing the authenticity and quality of this product. This connector is ideal for applications requiring a compact, robust, and easily installable rectangular connector solution.

Looking for more Harting connectors? [Click here to browse all Harting parts]
