Manufacturer Part Number (MPN) 21 43 320 1800
Manufacturer Harting
Short Description HARTING Han 3A-HMC-M-a2-LB-PG11, Male insert, Axial screw termination, 3+PE contacts, 16A, 500V, PG11
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Material
Polycarbonate (PC)
Wire Gauge
0.75 to 2.5 square millimeters
Locking Type
For Screw Locking
Mating Cycles
Greater than or equal to 500
Rated Current
16 Amperes
Rated Voltage
500 Volts
Connection Type
Axial Screw
Impulse Voltage
6 Kilovolts
Pollution Degree
3
Protection Degree
IP44, IP65/67 with Appropriate Housing
Temperature Range
-40 to +125 Degrees Celsius
Contact Resistance
Less than or equal to 1 milliohm
Number Of Contacts
3 plus Protective Earth
Insulation Resistance
Greater than 10 to the power of 10 Ohms
Flammability According To Ul94
V-0

Ordering Information

Parameter
Value
Weight
22.5 g
Packaging Type
BOX

Full Description

The HARTING 21433201800 is a robust male insert from the Han 3A series, specifically designed for heavy-duty power connector applications. This insert features axial screw termination, simplifying the wiring process and ensuring a secure and reliable electrical connection. With 3+PE (protective earth) contacts, it is rated for 16A and 500V, making it suitable for a wide range of industrial power applications. The PG11 thread provides a standard and secure mounting option. As an authorized distributor of HARTING components, Supreme Components International guarantees the authenticity and quality of this product. This insert is ideal for use in harsh environments where reliable power connections are critical. It is a key component for creating durable and dependable heavy-duty connectors.
