21 40 600 0886 075

Manufacturer Part Number (MPN) 21 40 600 0886 075
Manufacturer Harting
Short Description HARTING Han 40 HPR EasyCon Basic Set
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Category
Series
Han HPR
Wire Gauge
0.75 to 2.5 square millimeters
Housing Color
Dusty Gray (RAL 7037)
Rated Current
16 Amperes
Rated Voltage
500 Volts
Contact Plating
Silver
Contact Material
Copper Alloy
Housing Material
Die-Cast Aluminum
Pollution Degree
3
Termination Type
Screw
Locking Mechanism
Double Locking Lever
Number Of Contacts
40
Flammability Rating
UL 94 V-0
Degree Of Protection
IP65 and IP68
Insulation Resistance
Greater than 10 to the power of 10 Ohms
Operating Temperature
-40 to +125 degrees Celsius
Mating Cycles Durability
500 or more

Full Description

The HARTING Han 40 HPR EasyCon Basic Set (MPN: 21406000886075) is a heavy-duty power connector designed for reliable performance in harsh industrial environments. Manufactured by HARTING, this connector is part of their renowned Han HPR series, known for its robustness and durability. Supreme Components International is an authorised distributor of HARTING, guaranteeing the authenticity and quality of this product. The EasyCon design simplifies installation, reducing assembly time and costs. This connector is ideal for applications requiring high power transmission and resistance to environmental factors such as vibration, temperature extremes, and moisture. Typical applications include railway technology, wind energy, and industrial machinery. The Han 40 HPR EasyCon Basic Set ensures secure and dependable connections, contributing to the overall reliability of your system.
