Home Harting

21 34 262 6840 010

Manufacturer Part Number (MPN) 21 34 262 6840 010
Manufacturer Harting
Short Description HARTING Han 34 HPR EasyCon Hood, straight cable entry, M40
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Category
Type
Hood
Series
Han HPR
Material
Aluminium die-cast
Thread Size
M40
Reachcompliance
Yes
Ro Hscompliance
Yes
Locking Mechanism
Double Locking Lever
Surface Treatment
Powder-coated, RAL 7037 (dust grey)
Flammability Rating
UL 94 V-0
Degree Of Protection
IP68
Cable Entry Direction
Straight
Number Of Cable Entries
1
Ingress Protection Rating
IP68
Operating Temperature Range
-40 °C ... +125 °C
Corrosion Resistance Standard
acc. to EN 60068-2-11
Maximum Operating Temperature
+125 °C
Minimum Operating Temperature
-40 °C

Ordering Information

Parameter
Value
Weight
0.45 kg
Packaging Type
BOX

Full Description

The Harting 21342626840010 is a Han 34 HPR EasyCon hood, meticulously engineered for heavy-duty power connector applications. This robust hood features a straight cable entry and M40 threading, ensuring secure and reliable connections even in the most demanding environments. Designed for use with Han 34 HPR inserts, it provides exceptional protection against dust, water, and other environmental factors. The EasyCon design simplifies installation and maintenance, reducing downtime and improving overall efficiency. Supreme Components International is an authorised distributor of Harting, guaranteeing the authenticity and quality of this product. This hood is ideal for industrial machinery, transportation, outdoor installations, and any application requiring a rugged and dependable power connection. Benefit from Harting's renowned engineering and Supreme Components International's commitment to quality.

Looking for more Harting connectors? [Click here to browse all Harting parts]

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.
