21 03 821 4833

Manufacturer Part Number (MPN) 21 03 821 4833
Manufacturer Harting
Short Description HARTING Han 3A-HMC-as-M20, axial screw termination, male insert, 3+PE contacts, 10A, 250V, IP65/67
Datasheet 📄 Datasheet

Supreme Components is an authorized distributor of Harting. We do not carry stock of this item but can quote upon request. Submit your request using the form.

Product Attributes

TYPE
DESCRIPTION
Category
Wire Gauge
0.14 to 2.5 square millimeters
Mating Cycles
Greater than or equal to 10000
Rated Current
10 Amperes
Rated Voltage
250 Volts
Connector Size
3 A
Contact Surface
Silver
Insert Material
Polycarbonate
Contact Material
Copper alloy
Pollution Degree
3
Protection Level
IP65/IP67
Termination Type
Axial screw termination
Tightening Torque
0.5 Newton meters
Contact Resistance
Less than or equal to 3 milliOhms
Number Of Contacts
3 plus Protective Earth
Flammability Rating
V-0
Mechanical Operation
HMC
Insulation Resistance
Greater than 10 to the power of 10 Ohms
Operating Temperature
-40 to +125 degrees Celsius
Rated Impulse Voltage
4 Kilovolts

Full Description

The HARTING 21038214833 is a robust Han 3A-HMC-as-M20 male insert, specifically engineered for heavy-duty power connector applications. This insert features 3+PE contacts, capable of handling 10A and 250V, and boasts an IP65/67 rating for superior protection against dust and water ingress. The axial screw termination ensures a secure and reliable electrical connection, even in harsh industrial environments. This insert is part of the Han series, known for its modularity and durability. Supreme Components International is an authorized distributor of HARTING electronic components, guaranteeing the authenticity and quality of this product. It is suitable for a wide range of applications requiring reliable power connections in demanding conditions.
